0216 519 47 90
Pressure switch, DANFOSS RT113
SHIP BUILDING PRODUCTION, MARINE CERTIFIED
017-519666
Regulation range [bar] Pe: 0.00 - 0.30, Differential [bar]: 0.01 - 0.05, Contact function: SPDT, Reset function: Auto, Pressure connection type: G, Pressure connection size: 3/8, Pressure Male/Female: Male, Enclosure rating IP: IP66, Max. Working Pressure [bar]: 0.4
Product details
| Gross weight | 0.984 Kg |
| Net weight | 0.878 Kg |
| Volume | 4.519 Liter |
| EAN | 5702423120550 |
| Ambient temperature range [°C] [max] | 70 °C |
| Ambient temperature range [°C] [min] | -10 °C |
| Ambient temperature range [°F] [max] | 158 °F |
| Ambient temperature range [°F] [min] | 14 °F |
| Approval | BV CCC CE DNV EAC GL LVD NKK PZH RINA RMRS RoHS RoHS China TYSK LLC CDC EURO-TYSK UKCA |
| Contact function | SPDT |
| Contact rating | AC15=3 A, 400 V AC1=10 A, 400 V DC13=12 W, 220 V AC3=4 A, 400 V LR=28 A, 400 V |
| Differential [bar] [max] | 0.05 bar |
| Differential [bar] [min] | 0.01 bar |
| Differential [psi] [max] | 0.7 psi |
| Differential [psi] [min] | 0.1 psi |
| Electrical conn. Male/Female | Female |
| Electrical connection | Screwed cable entry |
| Electrical connection size | 2xPg 13.5 |
| Electrical connection standard | DIN 40430 |
| Electrical spec. standard | EN 60947-4/-5 |
| EN 60947 electrical properties | Pollution degree: 3 Rated impulse voltage: 4 kV Short circuit prot, fuse: 10A Insulation: 400V |
| EN 60947 wiring properties | Flex, ferrules: 0.2-1.5 mm2 Flex, no ferrules: 0.2-2.5 mm2 Solid/stranded: 0.2-2.5 mm2 |
| Enclosure rating IP | IP66 |
| In scope of WEEE and contain batteries | No |
| Max. test pressure [bar] Pe | 0.5 bar |
| Max. test pressure [psig] | 7 psig |
| Max. Working Pressure [bar] | 0.4 bar |
| Max. Working Pressure [psig] | 6 psig |
| Packing format | Multi pack |
| Pressure connection size | 3/8 |
| Pressure connection standard | ISO 228-1 |
| Pressure connection type | G |
| Pressure Male/Female | Male |
| Pressure sensing element | Diaphragm |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product group | Switches and thermostats |
| Product Name Description | Pressure switch |
| Quantity per packing format | 9 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Regulation range [bar] Pe [max] | 0.3 bar |
| Regulation range [bar] Pe [min] | 0 bar |
| Regulation range [psig] Pe [max] | 4.4 psig |
| Regulation range [psig] Pe [min] | 0 psig |
| Reset function | Auto |
| SCIP dossier no. | 54f3e4b2-77e8-4825-a1c1-c3d5ba584171 |
| Serviceable | Contact systems |
| Type | RT113 |
