| Model | Size | Way | Voltage | Operating Pressure |
|---|---|---|---|---|
| EAR-004-1111 & BLV-N132BP015M | 1/2" (DN15) | 3/2 | 230V AC | 0-40 Bar |
| EAR-004-1111 & BLV-N132BP020M | 3/4" (DN20) | 3/2 | 230V AC | 0-40 Bar |
| EAR-004-1111 & BLV-N132BP025M | 1" (DN25) | 3/2 | 230V AC | 0-40 Bar |
| EAR-004-1111 & BLV-N132BP032M | 1 1/4" (DN32) | 3/2 | 230V AC | 0-40 Bar |
| EAR-006-1111 & BLV-N132BP040M | 1 1/2" (DN40) | 3/2 | 230V AC | 0-16 Bar |
| EAR-006-1111 & BLV-N132BP050M | 2" (DN50) | 3/2 | 230V AC | 0-16 Bar |
| EAR-004-1211 & BLV-N132BP015M | 1/2" (DN15) | 3/2 | 24V DC/AC | 0-40 Bar |
| EAR-004-1211 & BLV-N132BP020M | 3/4" (DN20) | 3/2 | 24V DC/AC | 0-40 Bar |
| EAR-004-1211 & BLV-N132BP025M | 1" (DN25) | 3/2 | 24V DC/AC | 0-40 Bar |
| EAR-004-1211 & BLV-N132BP032M | 1 1/4" (DN32) | 3/2 | 24V DC/AC | 0-40 Bar |
| EAR-006-1211 & BLV-N132BP040M | 1 1/2" (DN40) | 3/2 | 24V DC | 0-16 Bar |
| EAR-006-1211 & BLV-N132BP050M | 2" (DN50) | 3/2 | 24V DC | 0-16 Bar |
General Information:
Duravis electric 3/2 ball valves feature three ports and are designed for flow direction control or for switching between two outlet lines with one inlet. Operated by an electric motor, they are ideal for use in applications requiring flow redirection. With a durable brass body and compact design, they ensure long-term reliability.
Technical Specifications:
-
Type: 3/2-way electric ball valve
-
Operating Voltage: 24 VAC/VDC or 220 VAC
-
Connection Type: Female threaded (BSP or NPT, depending on model)
-
Body Material: Nickel-plated brass
-
Sealing Material: PTFE (Teflon)
-
Flow Type: L-port or T-port (depending on model)
-
Working Pressure: Max 16 bar
-
Working Temperature: 0°C to +90°C
-
Control Type: ON/OFF or modulating (optional)
-
Operating Time: 8 – 15 seconds
-
Enclosure Protection: IP65
-
Available Sizes: 1/2", 3/4", 1", 1¼", 1½", 2" (may vary by model)
Applications:
Used in water and fluid routing systems, HVAC systems, automation processes, agricultural irrigation, process control, and bypass lines.
Mounting Position:
Can be installed in any position. Flow direction and port configuration (L or T) must be clearly marked on the valve body. Vertical installation is recommended.
