SIEMENS LAL2.25-110V BURNER AUTOMATIC

General Description:
The SIEMENS LAL2.25-110V is an electromechanical burner control box designed for multi-stage gas or oil burners. Specifically built for systems operating at 110V AC, this unit is used in safety-critical industrial burner applications where dependable ignition and flame supervision are essential.

Technical Specifications:

• Model: LAL2.25-110V

• Power Supply: 110 V AC, 50/60 Hz

• Burner Type: Multi-stage gas and oil burners

• Timing Functions:

  • Pre-purge time: 17 seconds

  • Safety time: 3 seconds

  • Main burner delay: 2 seconds

• Flame Supervision: Ionization probe or photocell (QRB, RAR)

• Reset: Manual reset

• Protection Class: IP40

• Operating Temperature: -20 °C to +60 °C

• Mounting: Panel mounting via AGK11 base

• Additional Features:

  • LED indicator for fault diagnostics

  • Integrated timing control

  • Supports multi-stage outputs

Applications:

• Industrial heating systems

• Commercial burner setups

• Special facilities using 110V AC systems

Advantages:

• Compatible with 110V supply

• Supports multi-stage burner control

• LED fault diagnostics

• Robust and reliable construction
